Wizard Mode
This operating mode is entered by pressing the WIZARD button. The Wizard walks you through the configuration and ring-out
procedure with simple, step-by-step instructions. By ringing out the system for feedback, higher system gain can be achieved
before the onset of feedback. This is accomplished by pushing your system into feedback so AFS can detect the frequencies
prone to feedback and then notch them out using Fixed filters. When the AFS Wizard is complete, it will automatically enable
the Live filters for automated protection during system use. See ‘Ringing Out The Sound System’ on page 19 for
further information on using the Wizard.
Menu Navigation Map
The below navigation map shows the navigational hierarchy of the AFS2 and how to navigate the unit.
CHANNEL
BYPASS
FILTER MODE
CONTENT MODE
FIXED FILTERS
CLEAR MODE
CLEAR <PRESS SELECT>
LIVE LIFT
LIFT AFTER
VIRTUAL HIGHPASS
SENSITIVITY
AFS Options Menu
Parameters:
LOAD PRESET
SAVE PRESET
FACTORY DEFAULT
Preset Menu
Parameters:
Preset Menu
STEREO LINKED
POWER UP OPTION
DISPLAY TIMEOUT
The currently
installed software
version can also be
found in this menu.
System Menu
Parameters:
AFS Options System Menu AFS Wizard
Information View
Home Screen
Filter Plot
Home Screen
Press the MENU/BACK button
Press the MENU/BACK button
Press the WIZARD button
Press SELECT to
toggle Home Screen
Press MENU/BACK
button
HOME MODE
WIZARD MODE
Turn the DATA wheel to make selections. Press the DATA wheel to conrm selections.
For further information on the menus and parameters in Menu Mode, see ‘The Menus & Parameters’ on page 24.
