27
Preset Menu
LOAD PRESET
Select this option to load a previously saved user preset, see ‘Loading Presets’ on page 21 for further information.
SAVE PRESET
Select this option to save the current settings as a preset, see ‘Presets’ on page 21 for further information.
FACTORY DEFAULT
Select this option to set all current settings back to their factory default state. This procedure will not delete presets from
memory. See ‘Factory Resets’ on page 23 for further information on this feature.
System Menu
The System menu allows you to edit global system parameters and view the currently installed firmware version.
STEREO LINK [NO, YES]
This parameter links the AFS2 for stereo linked operation when set to YES. When set to NO the two AFS2 channels will
work independently in dual mono operation. See ‘Linking/Unlinking Channels’ on page 18 for further information on
linking/unlinking channels.
POWER UP OPTION [Current, Preset1, Preset2, Preset3, Preset4, Preset5]
This parameter determines the settings that will be loaded after power-up. If the CURRENT option is selected, the AFS2 will
boot with the same settings it had when it was last powered down. If one of the PRESET options is selected, the AFS2 will
always boot with the settings saved in the selected preset.
DISPLAY TIMEOUT [10S, 30S, 1M, 2M, 3M, 4M, 5M, 10M, 15M, 20M, DISABLED]
This parameter enables/disables a timer which will cause the AFS2 to automatically lock out the front panel after a period of
user inactivity. The time is user selectable and ranges from 10 seconds to 20 minutes. After the set time expires, a PIN entry
page will appear on-screen, requiring the correct PIN to be entered before any AFS parameters can be seen or edited. The
PIN is a fixed number and is ‘1234’ . See ‘Front Panel Lockout’ on page 22 for further information on this feature.
