Control Bus LED
This LED (when lit) indicates that the 482 is sending/receiving network
information.
Remote LED
This LED (when lit) indicates that the 482 is sending/receiving from a
480R.
PC LED
This LED (when lit) indicates that the 482 is sending/receiving from a per-
sonal computer through the GUI interface.
Input Meters
The 482 provides the user with four independent 12 segment lightpipe™
input meters that range from -30 to +22 dBu.
Threshold Meters
The threshold meters indicate that the threshold level has been exceeded within the dynamics sec-
tion (compressor/limiter), and gain reduction is taking place within the specific output channel.
Output Meters
The 482 DriveRack™ provides the user with eight independent 12-seg-
ment lightpipe™ output meters that range from -30 to +22 dBu.
Output Mutes
The eight output mute buttons are used for independently muting each
output of the 482 DriveRack™.
Power Switch
Turns the 482 DriveRack™ on and off.
