dbx QUANTUM - Multiband Gate

Navigation
®
10
Section 2
QUANTUM
QUANTUM User Manual
2.3 Multiband Gate
Navigate through
the bands by
depressing the
"Gate" button
successively until
arriving at the
desired band
All
Bands
Band
1
Band
2
Band
3
Band
4
Navigating the "Multiband Gate"
Navigate through the Pages by depressing "Next Page" or "Prev Page"
successively until arriving at the desired Page
Gate On/Loc/Off
Threshold
Ratio
Attack
Hold
Release
Max Att
Band 1 On/Off
Threshold
Ratio
Attack
Hold
Release
Max Att
Band 2 On/Off
Threshold
Ratio
Attack
Hold
Release
Max Att
Band 3 On/Off
Threshold
Ratio
Attack
Hold
Release
Max Att
Band 4 On/Off
Threshold
Ratio
Attack
Hold
Release
Max Att
Page 1 Page 2 Page 3
