66
Appendix B
QUANTUM
®
QUANTUM User Manual
Figure 3b - Signal of Fig. 3a Going Beyond the A/D Clip Level
Amplitude
Time
A/D Clip Level
A/D Clip Level
Figure 3a - Signal Having Low and High Frequency Content
Amplitude
Time
TypeIV™ White Paper
