70
Appendix C
QUANTUM
not allow the user to change the termination setting. These pieces of equipment are usually provided with a permanent
termination. If you use QUANTUM with another piece of terminated equipment in a tapped configuration, you should
unterminate QUANTUM’s sync input. The same is true if you wish to use several QUANTUMs in a tapped configuration.
QUANTUM can also be used in a daisy chain fashion. In a daisy chain configuration, each piece of equipment can remain
terminated (and should if you are using a SuperClock) and so the termination can remain in the default position.
Whatever configuration you choose, always use high-quality 75 ohm coaxial cable for your sync connections. In addi-
tion, keep the cable runs as short as possible. The preceding is especially true when using SuperClock because the fre-
quencies are much higher. Failure to follow these guidelines could cause decreased audio performance and/or syn-
chronization problems.
C.2 QUANTUM Sync Input (cont.)
