General
The Grill is designed for easy placement into masonry enclosures. For non-combustible applications
the grill drops into the opening shown in (Fig. 04) and hangs from its side flanges. A deck is not
required to support it from the bottom. When using the insulated jacket in a combustible enclosure
application, see the bottom of Fig. 04. The jacket assembly must be supported from the bottom by a
ledge on each side or a solid deck beneath the entire grill or insulated jacket.
Review the detail drawing shown (Fig. 04) and take into account the provisions shown for gas line
hook-up clearance in the right rear corner. It is recommended that ventilation holes are provided in
the enclosure in the event of a gas leak. The supporting ledges or deck must be level and flat. The
counter should also be level.
LOCATING GRILL/BUILT-IN CLEARANCES
