33
Burner Electrodes
Burner Electrode
Smoker Burner Electrode
I/R Burner Electrode
IgnitionModule
6 Output
Ignition Switch
9 Volt Battery
Wiring Diagram
P/N # 32826
WIRING DIAGRAM BGA36-BQAR MODELS
#16440-03
#18351
#16281-02
#18354
#18353
#16281-06
#16441-02
#16281-04
