29
BGB48-BQR GRILL BODY PARTS LIST
ITEM DESCRIPTION PART NO.
27 Handle,Drip Pan,BGB48-BQR 33406
28 Drip Pan Assembly, Side Burner, BGB48-BQR 33405
29 Handle,Drip Pan,Side Burner 33408
30 Drip Pan,Side Burner 33407
31 Front Baffle,Sdie Burner 33402
32 Bottom Back,Sdie Burner 33401
33 Side,Side Burner 33400
34 *Insulated Jacket 48,Stainless Steel BGA48-IJS
35 Hanger Burner, BGA 132 33298
36 Aeration Pan W/A 33409
37 C-Clip Electrode 12231
38 Jet Holder LP 12200-17
Jet Holder NAT 12200-08
39 Nut,M22 Jet Holder 12150
40 Base D Burner 12321
41 Venturi 12332
42 Port Ring Assembly 12333
43 D Burner Cap 12272
44 Electrode 12224
45 Spring,Electrode 12230
46 Rubber Bumper 18403
47 I/R Protection Plate 41191-PC
48 Screw 15001-26
49 Shoulder Bolt 15089-1
50 Spacer Lid 32124-03
51 Acorn Nut 15019-04
* For use when building into
combustible enclosures (see
page 11 for built-in details)
ITEM DESCRIPTION PART NO.
1Lid,BGB36 33184
2Bolt 15003-06
3Stanchion,Lid Handle,R/H 18372-01
4Lid Handle,BGB48-BQR 55773-05
5Stanchion,Lid Handle,L/H 18372-02
6Warming Rack, BGB48-BQR 32248-01
7Wrapper, I/R burner 33179
8Screw 15001-23
9Service Panel, BGB36 33181
10 Firebox, BGB36 33200
11 Bottom/Back Panel,BGB36 33169
12 Rack Roller 14197-02
13 Shield, Smoker Valve 41198
14 Safety Valve Box 33068
15 Landing Ledge, BGB48-BQR 33398
16 Front Baffle,BGB48-BQR 33176-01
17 Logo Clip 15073
18 Valve Panel,BGB48-BQR 33403-PA
19 Screw 15001-23
20 Logo 17382-01
21 Drip Pan Assembly, BGB48-BQR 33404
22 Grease Tray 32771
23 Screw 15002-17
24 Keps Nut 15021-04
25 Nut 15004-09
26 Drip Pan,BGB36 33198
