25
Grill Body Parts List
ITEM DESCRIPTION PART NO.
1 Roll Top Lid 48DBQ/36DBQA 32293-01
Roll Top Lid 48DBQA 32293-02
Roll Top Lid 36DBQ 32293-03
Roll Top Lid 27DBQR 30602-27
2 Handle End Cap Spacer 18174
3 Handle End Cap 18164-PL
4 Shoulder Bolt 15089-3
5 Handle Tube 48DBQ/36DBQA 32048-02
Handle Tube 48DBQA 32048-01
Handle Tube 36DBQ 32048-03
Handle Tube 27 32048-05
6Warming Rack 48DBQ/36DBQA 32248-01
Warming Rack 48DBQA 32248-02
Warming Rack 36DBQ 32248-03
Warming Rack 27DBQ 32314
7 Firebox w/assy. 48DBQ/36DBQA 32247-01
Firebox w/assy. 48DBQA 32247-02
Firebox w/assy. 36DBQ 32247-03
8 Body Assembly 27D 32271
9 Bolt (small) 15002-26
10 Warming Rack Ret. 27 L/H 32340-01
Warming Rack Ret. 27 R/H 32340-02
11 Landing Ledge w/assy. 27 32043
12 Cage Nut 15029-02
13 Logo Spring Clip 15073
14 Valve Panel 48DBQR 32212-01-PA
Valve Panel 48DBQAR 32212-02-PA
Valve Panel 48DBQ 32212-07-PA
Valve Panel 48DBQA 32212-08-PA
Valve Panel 36DBQR 32212-03-PA
Valve Panel 36DBQ 32212-04-PA
Valve Panel 36DBQAR 32212-05-PA
Valve Panel 36DBQA 32212-06-PA
Valve Panel 27DBQ 32272-03-PA
Valve Panel 27DBQR 32272-01-PA
15 DCS Logo 17129-01
16 Torx Screw 15002-41
17 Drip Pan 48D 30645-2
Drip Pan 36D 30645-1
Drip Pan 27 32260
18 Drip Pan Handle 48D 32050-01
Drip Pan Handle 36D 32050-02
Drip Pan Handle 27D 32041
19 Screw 15002-17
Keps Nut 15021-04
Hex Nut 15004-09
20 Trim w/assembly 48D 32235-03
Trim w/assembly 36D 32235-04
