ADVANCE
Sectional door
electromechanical operator
Operating instructions and warnings
Index
1
Warnings Summary 25
6
Basic Functions 32
2
Product Description 27
7
Standard Programming 34
3
Technical data 28
8
Advanced Programming 36
4
Installation and Assembly 28
9
Messages shown on the Display 41
5
Electrical Connections
10
Start-up 42
5.1
- ADVANCE 30
11
Maintenance 42
5.2
- ADVANCE XL 32
12
Product Disposal 43
SYMBOLS
The following symbols are used within this manual to indicate potential hazards.
Important safety notice. Any failure to observe this notice could result in personal injuries or even death. Injuries. Any failure to
observe these instructions could result in serious damage or even the complete destruction of the product.
Important safety notice. Contact with the electrical power components could result in personal injuries or even death.
Important notice for professional installation, programming and commissioning.
1 WARNINGS SUMMARY
WARNING! IMPORTANT SAFETY INSTRUCTIONS. CAREFULLY READ AND FOLLOW ALL WARNINGS AND INSTRUC-
TIONS THAT ACCOMPANY THE PRODUCT SINCE INCORRECT INSTALLATION COULD CAUSE HARM TO PEOPLE, ANIMALS
OR THINGS. WARNINGS AND INSTRUCTIONS PROVIDE IMPORTANT INFORMATION REGARDING SAFETY, INSTALLATION,
USE AND MAINTENANCE. KEEP THE INSTRUCTIONS TOGETHER THE TECHNICAL DOCUMENTATION AND FOR FUTURE
REFERENCE.
WARNING The device may be used by children of less than 8 years of age, people
with reduced physical, mental or sensory impairment, or generally anyone without
experience or, in any case, the required experience provided the device is used under
surveillance or that users have received proper training on safe use of the device and are
aware of the dangers related to its use.
WARNING Fixed installation command (buttons, etc.) must be situated out of the
reach of children at a height of at least 150 cm from the ground. Do not allow children
to play with the device, the fi xed commands or the radio controls of the system.
WARNING Product use in abnormal conditions not foreseen by the manufacturer
may generate hazardous situations; meet the conditions indicated in these
instructions.
INTENDED USE:
The drive unit is designed for the automation of non-commercial garage doors and
balanced garage doors with integrated fall protection, within the specifi ed technical limits.
