27
WARNING Any external security devices used for compliance with the limits of impact
forces must be conform to standard EN12978.
WARNING In compliance with EU Directive 2012/19/EG on waste electrical and elec-
tronic equipment (WEEE), this electrical product should not be treated as municipal mixed
waste. Please dispose of the product and bring it to the collection for an appropriate local
municipal recycling.
E
VERYTHING THAT IS NOT EXPRESSLY PROVIDED FOR IN THE INSTALLATION MANUAL IS NOT ALLOWED. CORRECT OP-
ERATOR OPERATION IS ONLY ENSUED WHEN THE REPORTED DATA IS RESPECTED. THE COMPANY DOES NOT RESPOND
FOR DAMAGE CAUSED BY FAILURE TO COMPLY WITH THE INSTRUCTIONS CONTAINED IN THIS MANUAL. WITHOUT AF-
FECTING THE ESSENTIAL FEATURES OF THE PRODUCT, THE COMPANY RESERVES THE RIGHT TO MAKE ANY CHANGES
DEEMED APPROPRIATE AND AT ANY TIME IN ORDER TO TECHNICALLY, STRUCTURALLY AND COMMERCIALLY IMPROVE
THE PRODUCT WITHOUT BEING REQUIRED TO UPDATE THIS DOCUMENT.
2 PRODUCT DESCRIPTION
2.1 Models and contents of the package
The ADVANCE product range consists of a family of 24V electromechanical operators for balanced spring-operated doors and sectional
doors. All the motorized models require the use of control units (NET series). The ADVANCE drive unit is designed for the automation of
non-commercial garage doors and balanced garage doors with integrated fall protection, within the specifi ed technical limits.
The drive unit can be used on the following types of doors:
Sectional doors Side tilting doors
Check the “Packaging content” (Fig. 1) and compare them with your product; this could be useful during assembly.
2.2 Transport and storage
The ADVANCE models are always delivered in boxes that provide the product with adequate protection; always respect the storage and
handling indications shown on the boxes themselves. Depending on the version and the track type, the furnished product may differ from
the illustrations contained within this manual. The drive unit must be stored/transported lying down at a temperature of -20°C to +40°C,
with a relative humidity value of RF 20 - 80%, without condensation. The maximum height of the stacks are as follows: 6 motor heads, 6
tracks or else 6 complete Kits packed in cardboard boxes. The stacked units must be secured in order to prevent tipping.
