Dea NET724N User Manual

31
ADVANCE WIRING DIAGRAM
(2x1,5 mm
2
+ 4x0,5 mm
2
)
PLUG CABLE/ADV (cod. 397321)
INTERNAL WIRING SET BY THE FACTORY
EXTERNAL WIRING SET BY THE INSTALLER
MOT 1
MOT 1
FLASH
Plug
Motor Terminal Block
IN 4 IN 3
4567123 8
19 18
MOT 1
IN 2 IN 1
COM
J4
CON3
CON1
CON2
CON2
OUT 1 OUT 2
+24V_ST
CON4
ENC (M1)
ENC A
+
ENC B
-
91314151610 11 12 17
RG58
F1
POWER SUPPLY
230V~ 50Hz ±10%
H05VV-F 3x0,75mm
2
F
N
230V
25V
TX RX
COM
N.C.
N.O.
N.O.
START
2 x 0,5 mm
2
2 x 0,5 mm
2
PHOTO 1
OPEN GATE
WARNING LIGHT
24V max 5W
COURTESY LIGHT
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
FLASHING LIGHT
24V max 5W
FLASH
CON5
ENC
ENC A
+
ENC B
-
YELLOW
GREY
BROWN
WHITE
GREEN
PINK
YELLOW
GREY
BROWN
WHITE
GREEN
PINK
