Dea REV Series User Manual

20
2 PRODUCT DESCRIPTION
Models and contents of the package
ThenameREVidentifiesaseriesofelectromechanicaloperatorsforslidinggateswithdifferentfeaturesastomotorandcontrol
boardpowersupplyvoltage,capacity,mechanicaladjustmentofforce,electronicclutchandbuilt-inlimitswitch.Allautomatedmo-
delsinvolvetheuseofadvancedcontrolunits(NETseries)equippedwithanti-crushingsensor,built-in433MHzradioreceiver,speed
controlandslowdowninopeningandclosing.TheREVmodelsareintendedprimarilyforresidential/condominiumandSemi-
intensive/intensiveusedependingonthedutycycleforeseenfortheautomation.
REViscompletedbyasetofaccessorieslistedinthe“PRODUCTACCESSORIES”table(page114).
REViscomposedofamechanicalgearmotorwhichrotatesthedrivinggear;Thisgear,coupledtotherackproperlyinstalledonthe
gate,convertsthecircularmotionofthegearmotorintorectilinearmotionthusallowingthemovementofthegateonitsownguide.
Inspectthe“ContentsofthePackage”(Pic.1)andcompareitwithyourproductforusefulconsultationduringassembly.
Transport
REVisalwaysdeliveredpackedinboxesthatprovideadequateprotectiontotheproduct,however,payattentiontoallinforma-
tionthatmaybeprovidedonthesameboxforstorageandhandling.
3 TECHNICAL DATA
REV220 - REV220/M -
REV220/IB
REV220/RF - REV220/RFM -
REV220/RF/IB
REV24/F - REV24/M -
REV24/IB
Motor power supply voltage (V) 230V~±10%(50/60Hz) 24V
Absorbed power (W) 500 250
Max Thrust (N) 900 1200 450
Work cycle
(leaf L=8m)
up to 1000 Kg 27cycles/hour 36cycles/hour
up to 1400 Kg 22cycles/hour 31cycles/hour
Maximum n° of opera-
tions in 24 hour
(leaf L=8m)
up to 1000 Kg 270 300 300
up to 1400 Kg 220 250 250
Built-in capacitor (µF) 18 -
Operating temperature range (°C) -20÷50°C
Motor thermal protection (°C) 150°C -
Opening speed (m/min) 10 12
Weight of product with package (Kg) 18
Protection degree IPX4
OPERATOR
CONTROL BOARD
NET24N
Power supply (V)
230V~±10%(50/60Hz)
Rated power transformer (VA)
250VA(230/22V)
Fuse F2 (A) (transformer)
2A
Batteries
2x12V1,3A
Fuse F1 (A) (batteries input)
15A
24V operators outputs
1x10A
Warning:Theabovevaluesarecalculatedbytakingthemaximumpower
suppliedbytherespectiveprocessors.Inabsoluteterms,themaximumcurrent
fromeachoutputmustnotexceed10A.
Auxiliaries power supply output
+24V max200mA
“Warning” output
+24V max15W
Electric lock output
24V max5Wormax1
art.110
Flashing light output
24V max15W
Operating temperature range (°C)
-20÷50°C
Receiver frequency
433,92MHz
Transmitters type of coding
HCSfix-code-HCSrollingcode
-Dip-switch
Max remote controllers managed
100
NET230N
Power supply (V)
230V~±10%(50/60Hz)
Fuse F2 (A)
5A
Fuse F1 (A)
160mA
230V operators outputs
2x600W
Auxiliaries power supply output
24V~max200mA
“Warning” output
230V~max150W
Electric lock output
max1art.110or24V 
outputmax5Wconfigurable
230V Flashing light output
230V~max40W
24V Flashing light output
24V max100mA(forled
flashinglight)art.LED24AIor
opengatewarninglight/courtesy
light
Operating temperature range (°C)
-20÷50°C
Receiver frequency
433,92MHz
Transmitters type of coding
HCSfix-code-HCSrollingcode
-Dip-switch
Max remote controllers managed
100
