Dea REV Series User Manual

21
4 INSTALLATION AND ASSEMBLY
4.1 For a satisfactory installation of the product is important to:
• Ensurethatthefacilitycomplieswithcurrentregulationsandthendefinethefullprojectoftheautomaticopening;
• Ensurethatthroughoutthecourseofthegate,whileopeningandclosing,therearenofrictionpoints;
• Ensurethatthereisnodangerofderailmentandthattherearenotrisksthatitgoesoutoftheguides;
• Makesurethegateisinequilibrium:itmustnotmoveifitstaysinanyposition;
• Ensurethatthemountingareaofthemotorallowsthereleaseandamanualoperationeasierandsafer;
• Ensurethatthemountingpositionsofthevariousdevicesareprotectedfromimpactsandthesurfacesaresufficientlyrobust;
• Donotallowtheautomationpartsareimmersedinwaterorotherliquids.
4.2 Defined and satisfied these prerequisites, proceed to the assembly:
If the supporting plane is already available, the fixing of the motor must be done directly on the surface using, for example
screw anchors or chemical means.
Alternatively, proceed as follows:
• MakeaholeappropriatetothetypeoflandbyusingasareferencethemeasurementsshowninFig3;
• Provideanadequatenumberofchannelsforthepassageofelectricalcables;
• Placethebaseofthefoundation;
• Startcastingofconcreteand,beforeyoustarttaking,bringingthebaseplatetothedimensionsshowninFigure4,makingsure
thatisparalleltothegatewingandperfectlylevel.Waitforthecompletesettingoftheconcrete;
• Removethenutsfromtheplate,thenputthemotoronthebasisoffoundation.
If the rack is already present, place the pinion at a distance of 1-2 mm in order to avoid that the weight of the wing could
burden on the gear motor. To do this, adjust the height of the REV with the grains (Fig. 5) and then tighten the nuts in a robust
way.
Alternatively, proceed as follows:
• Unlockthemotorandfullyopenthedoor;
• Placethefirstsectionoftherackonthewing,makingsurethatthestartoftherackcorrespondstothetopofthewing.Then
attachtheracktotheleafkeepingagameof1-2mmfromthepinion(Fig.6);
• Cutofftheexcesspartoftherack;
• Finally,movethedoormanuallyseveraltimesandverifythatthealignmentandthedistanceof1-2mmbetweentherackand
pinionisrespectedthroughoutthelength;
• TightenthelocknutsofREVinarobustway(Fig.7)andcoverwithplasticcaps.
4.3 How to unlock the operator
Onceyouopenthelockonthehandle(protectedbyaplasticcover),thelevermustbeturnedinthedirectionshowninFig8,at
thispointtheoperatorisunlockedandthegate,intheabsenceofotherobstaclesisfreeinhismovements.Thereverseprocess,turn
theleveruntilitstopsandclosingofthelock(remembertoprotectthelockwiththepropercover),keepsREVinworkingcondition.
4.4 Limit-switches
Adjustment of the limit-switches
SomeREVmodelsprovidesalimit-switchwhoseinterventionmustbeadjustedforeachinstallation.DEASystemprovidestwolimit
switchescams(Fig.9)thatareinstalledontherackofthegateandsubsequentlyregulatedinsuchawayastoensurethefunctio-
nalityandsafetydistancesinopeningandclosingofthegate.
Keepinmindthatwhenthelimitswitchestrigger,thedoorwillmovetoanother2-3cm,andit’sthereforesuggestedtofixtheend
ofstrokebracketsatasufficientdistancefromthemechanicalstops.
Adjustment of the magnetic limit switch
AttachthemountingbracketstothemagnetsasshowninFigure11,making sure to mount the LIGHT BLUE magnet at the closing limit
switch, the GREEN magnet at the end of the opening limit switch(Fig.12).Connect the cable of the magnetic sensor which is colored
BROWN at the FCC 1 input (Closing Limit Switch 1) and the BLACK one at FCA 1 input (Opening Limit Switch 1)(Fig.13);
WARNINGRefertocontrolboardinstructionstocorrectlyidentifythelimitswitchinputs.
WARNINGIncorrectinstallationofthemagnetscanbedangeroustopeopleorthings;observetheconditionsprescribedinthesein-
structions.
MountthemagneticsensorasshowninFig.10.Thesensormustprotrudefromthebracketforsupportingatleast30mm,inthiswaywill
avoidanyinterference.
Adjustthemagnetssupportbracketssoastomaintainadistancefromthesensorbetween10and20mm;
4.5 Non self locking models
Nonselflockingmodelsallowthegatetomovemanually,withouthavingtouseareleasekeywhenthepowerfails.Nonself
lockingversionsareequippedwithaholdingbrakewhenopening/closing,Thismeansthegatewillbeselflockinginnormalope-
ration.
Refertotheattachedsheetforthecorrectprocedureofcleaning/maintenanceoftheelectro-brake.DEASystemremindsthat
theoperationsmustbeperformedbyqualifiedpersonnel.
