DECTRON
Dectron, Inc. March 2012
DSH/DSV/RSH/DBH/RBH Series Dehumidifier Owner’s Manual
T.A.B. Set Optional DryCooler Flow
Data subject to change without notice.
202
CONDENSER FLUID FLOW - units with Dry-Cooler-cooled air conditioning only
Some units may be equipped with an optional DryCooler heat exchanger. In this case, instead of an outdoor
condenser there will be a pumped-glycol loop connecting the unit to an outdoor fan-coil.
During cooling modes, units with DryCoolers require the glycol flow rates shown here.
Request and refer to Appendix M1 DryCooler
.
010 8(30)
015 10 (38)
020 14 (53)
030 20 (76)
040 28 (106)
042 28 (106)
050 36 (136)
060 45 (170)
062 40 (151)
080 54 (204)
082 56 (212)
100 73 (276)
102 73 (276)
120 94 (356)
122 94 (356)
150 107 (405)
152 107 (405)
162 127 (481)
164 112 (424)
182 145 (549)
184 146 (553)
202 160 (606)
204 167 (632)
242 178 (674)
244 188 (712)
282 210 (795)
284 214 (810)
362 276 (1045)
364 290 (1098)
368 292 (1105)
402 320 (1211)
404 320 (1211)
408 334 (1264)
482 375 (1420)
484 376 (1423)
488 376 (1423)
562 437 (1654)
564 420 (1590)
568 428 (1620)
804 640 (2423)
808 640 (2423)
Size
GPM (Lpm)
Glycol
Measured DryCooler Circuit 1 (if any)-Water Flow
Measured DryCooler Circuit 2 (if any)-Water Flow
Measured DryCooler Circuit 3 (if any)-Water Flow
Measured DryCooler Circuit 4 (if any)-Water Flow
NOTICE
Risk of unit damage.
Excessive flow rates can damage heat exchangers.
Inadequate flow rates can cause failure to operate and can
damage heat exchangers.
Remove the jumper(s) installed on first page
previous.
