The RF-360 Dedrone
6 v0.4 IM-Inst-RF360en
Parts of the RF-360
A
RF-360
C
Cover screw
B
Cover
D
Grip recess and activation button
2 The RF-360
The RF-360 is a passive, network-attached or cloud connected sensor for the detection and direc-
tion finding of radio frequencies (RF) and Wi-Fi signals. In combination with two or more RF-360 it
is able to determine the position of a drone by the RF signals. The RF sensor detects targeted radio
signals, identifies their direction and sends the data, along with an alert via LAN or mobile data to
the DroneTracker System.
B
C
A
D
It scans a wide frequency band for radio frequencies and classifies them. The data is recorded and
available on the user interface DroneTracker UI.
3 Unpacking
This equipment should be unpacked and handled with care. Check the exterior of the packaging for
visible damage. If an item appears to have been damaged in shipment, notify the shipper immedia-
tely.
Despite careful construction, electrical devices can cause fires. Do not mount the RF-360
in areas containing highly flammable materials or gases. Do not mount the RF-360 in a
potentially explosive atmosphere.
Do not install product near any heat sources such as radiators, heaters, exhaust air sys-
tems or other equipment (including amplifiers) that produce heat.
