Integrate the RF-360 in your DroneTracker

For further information consult chapter “First Steps” of the integrated online help in the
DroneTacker user interface.
7.2 Integrate the RF-360 via Dedrone Cloud
Requirements:
` RF-360 is installed
` The power supply is working and the LED at the RF-360 illuminates blue
` RF-360 is connected to the Dedrone Cloud
` The address of your Dedrone Cloud access is known (provided by Dedrone)
` The registration key of the sensor is available (provided by Dedrone)
Procedure:
1
Start your web-browser and enter the address of your Dedrone Cloud.
For an optimal use, Dedrone recommends Chrome or Firefox.
2
Log in the DroneTracker UI as an administrator or configurator.
3
Choose OPTIONS > Site Configuration.
4
Choose [Add] > Register device.
 The window Register device appears.
5
Enter the registration key of your sensor and choose [OK].
 The RF-360 appears in the Site Explorer.
6
To sort the RF-360 in the Site Explorer, drag and drop the element to the desired position.
7
Choose [Save changes].
 The window Site Configuration disappears.
8
Choose OPTIONS > Map Editor and choose the RF-360.
9
An accurate alignment of the sensor and configuration in the
DroneTracker are prerequisites for a good direction finding result.
If the sensor was aligned via a prominent landmark, drag and drop the sensor symbol to
the installed position and move the arrow to the chosen prominent landmark.
If the sensor was aligned via a GPS device, choose the element on the map and enter the
noted values in the fields Latitude, Longitude and Azimuth.
10
To lock the settings, choose the option Lock settings.
11
Choose [Save changes].
 The window Map Editor disappears.
