2.3 Product Diagram
Robot
1. Top Cover
2. Dust Bin
3. AUTO Mode Button
4. Anti-Collision Sensors
5. Anti-Drop Sensors
6. Charging Contacts
7. Main Brush
8. Driving Wheels
9. Universal Wheel
10. Battery Pack
11. Side Brushes
12. Advanced Wet/Dry Reservoir Slots
13. Multi-Function Cleaning Tool
14. Upgrade Port (for Customer Service only)
15. Infrared Receiver for the Remote Control
1
3
2
4
5
6
7
8
13 1514
9
10
11
12
2. Package Contents and Technical Specications
Charging Dock
1
1. Infrared Signal Generators
2. Charging Dock Pins
1. AUTO Mode Button
2. Wi-Fi Indicator Light
Control Panel
1
2
2
