Page 8
x Insert the oven into the cupboard.
x Open the door to expose the fixing holes in the side trims.
x Secure the oven by 4 countersunk screws (fasteners are not supplied).
590
Aperture
Typical section showing
ventilation requirements.
565
900
Above floor
level
Floor
60
+
_
3
0
+
_
3
0
+
_
3
0
+
_
3
0
APERTURE
590 H X 565 W X 570 D
Built in oven cut outs. Cupboard aperture for models 600SU and 600U
Worktop
32mm - 48mm thick
Vent
gap
at
front
only
100
590
Aperture
(210)
Floor
Datum
900
565 Aperture
Top filler piece
Typical section showing
ventilation requirements.
Aperture
590 H x 565 W x 570 D
6
+
_
3
0
+
_
3
0
+
_
3
0
Eye-level oven installation for models 600E and 600SE
Aperture
