Page 31 from 69
9. Functionality
User interface – Push buttons
Two keys are available for operation on the device.
These have different functions depending on how long they are pressed.
Push button Duration function
1 (Option)
short (<1 sec) Start fast data transfer
long (>5 sec) Device stop/start
long (>10 sec) Reset to factory settings
2 (Basic)
short (<1 sec) Activate web server
long (>5 sec) Device reset
Push button 1 (Option)
Push button 2 (Basic)
