10. Device settings
10.1 Device settings expert mode
Device settings can be made on the web server of the DEHNrecord SD itself, via Modbus or via the cloud. For easy operation, some more
complex setting options are hidden by default. If the expert mode is activated, all setting options can be displayed.
10.2 General
In addition to a description, the path for the configuration of power quality parameters can be specified here.
Path for PQ configuration Comment
Modbus Limit values can be set via the Modbus
Cloud Limit values can be set via the cloud
10.3 LED indicator
The display of LED 2 (Status) can be configured individually. The following options are available for this purpose:
Configuration LED 2 (Status) green yellow red
PQ status standard OK Event occurred Violation of a limit value
PQ status individual OK Event occurred Violation of a limit value
POP display OK Event occurred -
Input 1
“0“ “1“
-
Input 2 -
Input 3 -
Off - - -
