10.4 Digital inputs, digital outputs and logic
Digital Inputs
For the three digital inputs (input 1, 2 and 3), both an event type and an event trigger can be defined.
The event type describes in which form and when events are transmitted to a cloud per 10-minute interval:
Event type Transmission
Off No event is transmitted
Instant event Only the first event is transmitted immediately
Collection event The number of events is transmitted at the end of the 10-minute interval
The event trigger defines the kind of signal change to which the inputs react:
Event trigger Input reacts to signal change
On change at rising and falling edge
Rising edge with rising edge
Falling edge with falling edge
10. Device settings
