10. Device settings
The digital output responds to various internal or external event sources.
The following options are available as sources:
Source Reaction to
Off -
Input 1 Event at digital input 1, behavior of the input adjustable
Input 2 Event at digital input 2, behavior of the input adjustable
Input 3 Event at digital input 3, behavior of the input adjustable
POP function
Detection of a power frequency overvoltage or individually defined voltage
(see chapter “power frequency overvoltages (POP)“)
PQ standard Violation of a PQ limit according to EN 50160
PQ individual Violation of a PQ limit according to individual set of limit values
Impulse Violation of an impulse limit*
Energy/current Events caused by the current and energy measurement (see chapter 10.6 current measurement)
Device
Events generated by the DEHNrecord SD itself, such as cloud connection established or action by pressing a button
on the device (Action 1, Action 2), firmware update successfully performed, ...
Cloud2Device A command controlled from the cloud
Logic Digital output functions as output of the LOGIC function
* Variant with impulse current measurement expected to be available from Q4 - 2021
