AL8-2 – Programming manual
4189320003D
Page 2/19
CONTENTS:
BEFORE YOU START PROGRAMMING .................................................................... 3
THE PRINCIPLE OF PROGRAMMING ........................................................................ 6
WHICH FUNCTIONS MAY BE PROGRAMMED? ....................................................... 7
HOW TO PROGRAMME INDIVIDUAL FUNCTIONS (INPUTS 1 TO 8)....................... 8
ALARM
ON OPEN OR CLOSED SIGNAL CONTACT (N/C, N/O) ............................. 9
SELECTION OF OUTPUT RELAY (OUTPUT(S) A AND/OR OUTPUT B) .............. 10
INHIBIT
OF INCOMING ALARM (INHIBIT) ............................................................. 10
ALARM
ON CABLE FAILURE (CABLE FAILURE) .................................................. 11
TIME
DELAYED REGISTRATION OF AN ALARM CONDITION (DELAY OF
ALARM) .................................................................................................................. 11
SELECTION
OF REQUESTED TIME DELAY (SET TIME) ..................................... 12
SELECTION OF BASIC TIME: .......................................................................... 13
SELECTION OF ADDITIONAL TIME: ............................................................... 14
PROGRAMMING OF COMMON FUNCTIONS .......................................................... 15
SELECTION
OF ACTIVATION/DEACTIVATION OF OUTPUT RELAY A ON AN
ALARM CONDITION (N/O, N/C) ............................................................................. 15
SELECTION
OF TIME LIMITED ACTIVATION/DEACTIVATION OF OUTPUT
RELAY A ................................................................................................................. 16
SELECTION OF ACTIVATION/DEACTIVATION OF OUTPUT RELAY B ON AN
ALARM CONDITION (N/O, N/C) ............................................................................. 17
SELECTION
OF TIME LIMITED ACTIVATION/DEACTIVATION OF OUTPUT
RELAY B ................................................................................................................. 17
DELAYED CANCELLATION OF INHIBIT FUNCTION (0..40 SECS) ......................... 18
"MASTER"/"SLAVE" CONFIGURATION .................................................................. 19
