AL8-2 – Programming manual
4189320003D
Page 4/19
Secondly, the bezel and front sheet are removed to give access to the programming
front plate.
The descriptive text for alarm channels 1-8 and the output channels A and B is
written/set on the shown text label.
We recommend using "letter-press" to set the text (height: 2.7mm) or typing the text on
the label.
Please note that the horizontal lines at both sides of the label indicate lines to be
written on
. Do not write between the lines.
