Deif Multi-line 2 Description Of Options

GPC, PPU Option O1, Water turbine control
DEIF A/S Page 5 of 19
Slot #1, power supply PCB
Term.
Function Technical data Description
1 +12/24V DC 12/24V DC
-25/+30%
Power supply
2 0V DC
3 NC Status relay Normally closed relay, processor/power supply
status supervision
4 Com. 24V / 1A
5
NO Relay 1
Configurable/jet deflector operation
6 Com. 250V AC / 8A
7 NC
8 NO Relay 2 Configurable
9 Com. 250V AC / 8A
10 NC
11 NO Relay 3 Configurable
12 Com. 250V AC / 8A
13 NC
14 NO Relay 4 Open breaker (deload)
15 Com. 250V AC / 8A Can be configured for tripping also
16 NC
17 NO Relay sync. Close breaker (synchronising)
18 Com. 250V AC / 8A
19 NC
20 Open
collector 1
Transistor out Pulse output 1, kWh counter
21 Open
collector 2
Transistor out Pulse output 2, kvarh counter
22 Com. Common Common terminal for terminals 20 and 21
23
Binary input Optocoupler Remote alarm inhibit/configurable
24
Binary input Optocoupler Remote alarm acknowledge/configurable
25 Binary input Optocoupler Start sync./control functions/configurable
26
Binary input Optocoupler Ext. communication control/configurable
27
Binary input Optocoupler Block loss of mains/configurable
28 Com. Common Common for terminals 23-27
The PCB in slot #1 is installed in all GPC and PPU units. It is shown in this
document because the jet deflector relay and feedback is placed on this PCB
(terminal 23, 24, 26 or 27).
Terminal 25 cannot be used for jet deflector feedback.
