WSI, WSDI, WSS or WSS-L User’s Manual
DEIF A/S
Page 11 of 19
Connection of the display type WSDI
Pin no. Function Note
AC Supply 220V AC or
110V AC
To change from 220V AC to 110V AC or vice
versa, see page 8
AC
GND EARTH The ship’s hull, it is not necessary to connect this
terminal
1 AUX +5V
DC
External mode
control
For external dimmer and read-out of m/s or KTS in
the display
2 0V Input from
WSS interface
box
Terminal 12 on the interface box, WSI
3 Wind speed Terminal 10 on the interface box, WSI
4 Direction Terminal 11 on the interface box, WSI
5 Screen The cable screen. Do not connect the other end
A Signal NMEA NMEA0183 version 1.5 or 2.x-3.0, see page 7.
B Return
Screen The cable screen. Do not connect the other end
9 Mode shift m/s or KTS Read-out in the display
10 Dimmer
