6. Technical information
Wind sensor type WSS
Power supply 12V DC ±20% (max. 1.1A)
24V DC ±20% (max. 0.6A)
Temperature working range -52…+60° C
Weight 0.8kg
Dimensions See drawing in chapter 3 of this manual
WSS interface box
Power supply 24V DC, working range 18-32V DC
Power consumption 0.9A at 24V DC (1.25A at 18V DC)
Fuse Recommended fuse 2A slow blow
Weight 0.45kg
Dimensions See drawing in chapter 7 of this manual
Display type WSDI
Power supply 110V AC or 220V AC
Power consumption 6W
Weight 0.8kg
Dimensions See drawing in chapter 7 of this manual
NMEA 0183 Version 1.5 or version 2.x-3.0
Transmission speed 4800 Baud
Number of bits 8
Number of parity bits 0
Number of stop bits 1
Transmission interval 1 sec.
Communication protocol NMEA 0183 version 1.5
$IIMWD,xxx,T,,,yy.y,N,,*zz<CR><LF>
Wind direction (0…360°) xxx
Wind speed (0.0…99.9 KTS) yy.y
Hexadecimal check sum zz
(XOR of all characters until the "*"-character (not included))
End of transmission (EOT) <CR><LF>
Communication protocol NMEA 0183 version 2.x-3.0
$WIMWV,xxx.x,R,yy.y,N,A*zz<CR><LF>
Wind direction (0...360.0°) xxx.x
Wind speed (0.0…99.9 KTS) yy.y
Hexadecimal check sum zz
(XOR of all characters until the "*"-character (not included))
End of transmission (EOT) <CR><LF>
