Delfi DelfiScan C51 - Keyboard Interface Control

DelfiScan
Programming Manual
Configure Your DelfiScan
27
PROGR
AM
Keyboard Interface Control
Keyboard Layout (Language) Setting
M_DEF
AULT
Family Code Selection P.C Parameter Selection Option Code
Keyboard Layout
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
USA (QWERTY)
France (AZERTY)
Germany (QWERTZ)
United Kingdom - UK (QWERTY)
Canadian French (QWERTY)
Spain (QWERTY)
Sweden/Finland (QWERTY)
Portugal (QWERTY)
Norway (QWERTY)
Latin America (QWERTY)
Italy (QWERTY)
Netherlands (QWERTY)
Denmark (QWERTY)
Belgium (AZERTY)
Switzerland-Germany (QWERTY)
Iceland (QWERTY)
Japan (DOS/V)
Universal * (see note)
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
99

The “
Universal Selection
” is only for PC/AT, PS/VP, PS/2 and compatible ones in
DOS
or
Windows
environment which can perform uniq
ue output
without
C
aps Lock on/off (Output Style) concern. All transmitted data will follow the original full ASCII form. You also need not worr
y about the
upper/lower case control.

Please refer to the
ASC
II/HEX Table
listed in the Appendix to determine HEX codes for characters, symbols, and functions to be used as premble or
postamble.

To set preamble or postambl
e as function key output, you must enable the
“Function Key Emulation”
feature as listed in page 3-25 first.

Keyboard Interface Message String :
Preamble Data Length Prefix Symbol ID
Scanned Data
Suffix Symbol ID Postamble Record Suffix
1-15 characters 2-3 digits 1 or 2 characters Variable length 1 or 2 characters 1-15 characters 1 character
