Programming Procedure
[Data Verifier]
 Scan “Program” to enter the programming mode.
 Scan “Verifier Control” and set bar code symbology to “48”
(Interleaved 2 of 5).
 Scan “Identified Data Length” and set the length to “16”.
 Scan “1st Identified Character” and set the identified position
to “00”, then set the identified character to “39” (Hex Code of
9).
[Data Formatter]
 Scan “Formatter Control” and set bar code symbology to “48”.
 Scan 1st Insertion” and set the identified position to “06”, t h e n
inserted characters to “09” (Hex Code of TAB), “53” (Hex Code
of S), “4E” (Hex Code of N).
 Scan “2nd Insertion” and set the identified position to “12”,
then inserted character to “09”. In the final, you must scan
“FIN” (Finish) code to terminate this selection.
 Scan “3rd Insertion” and set the identified position to “16”,
then inserted character to “09”. In the final, you must scan
“FIN” (Finish) code to terminate this selection.
[Data Replacer]

Scan “Replacer Control” and set bar
code
symbology to
“48”.
 Scan “1st Replacement” and set the identified position to
“00”, then replaced character to “41” (Hex Code of A).
[Data Organizer]

Scan “Organizer Control” and set bar code symbology to
“48”.
 Scan “1st Organization” and set the identified position to
“16”, then set the data transmission to “0” (forward).
 Scan “2nd Organization” and set the identified position to
“17”, then set the data transmission to “1” (backward).
 Scan “END” (Exit) to terminate the programming.
[Important Notice]
Please note that Condensed DataWizard will follow the preset
working flow as below:
Verifier Formatter Replacer Organizer
So when you set the identified position in Data Organizer,
you must consider the inserted data which you already set
via Data Formatter.
