DelfiScan
Programming Manual
Configure Your DelfiScan
46
Select a B
ar Code Symbology
You can select one or all types of bar code symbologies to use
Condensed DataWizard for advanced transmission arrangement.
If you scan “00” to select all types, the DelfiScan will arrange all
incoming data to meet your pre-defined format. If you want to
select only one type bar code, please select one of the option
code listed below.
Code 128 :
01
UCC/EAN 128 :
31
UPC-A :
02
UPC-A with 2 supple.:
32
UPC-A with 5 supple.:
42
UPC-E :
03
UPC-E with 2 supple.:
33
UPC-E with 5 supple.:
43
EAN-13 :
04
EAN-13 with 2 supple. :
34
EAN-13 with 5 supple. :
44
EAN-8 :
05
EAN-8 with 2 supple :
35
EAN-8 with 5 supple.:
45
Codabar/NW-7 :
06
Code 39 :
07
Code 32 :
37
Trioptic Code 39:
47
Matrix 2 of 5 :
38
Interleaved 2 of 5 :
48
China Postal Code :
58
German Postal Code :
68
Code 93 :
09
Code 11 :
10
MSI/Plessey :
11
UK/Plessey :
12
Telepen :
13
GS1 Data Bar :
14
IATA :
15
Coupon Code :
16
PDF417/MicroPDF417:
22
Codablock:
23
Korea Post Code:
26
Position Calculation
[Data Formatter]
If there is a 5-character input data string, refer to the following to
calculate the actual position for insertion:
X X X X X
00 01 02 03 04 05
[Data Verifier, Data Replacer, Data Organizer]
If there is a 11-character data string, please refer to the
following to calculate the actual position for identification.
X X X X X X X X X X X
00 01 02 03 04 05 06 07 08 09 10
Application Example
If your bar code label is a 16-digit Interleaved 2 of 5 which
includes the information of 6-digit date code, 6-digit serial
number and 4-digit unit price, you want the DelfiScan do the
following for you without software modification:
Apply only Interleaved 2 of 5 to the cond
ensed
Da
taWizard.
Check bar code is actually with 16-digi
t length.
All
ow bar code output whose date code is leading with “9”.
Three outputs with “TAB”
suffix.
The date cod
e output should skip “9” and replaced it by “A”.
The serial number output should be led with “SN”
.
T
he unit price output should be skipped the first 2 digits
.
Te
st Bar Code : 9 8 1 0 2 5
1 2 3 4 5 6 9 8 7 6
Actual Output : A81025[TAB]SN123456[TAB]76[TAB]
