DelfiScan
Programming Manual
Configure Your DelfiScan
33
PROGR
AM
Serial Interface Control
Protocol, Baud Rate, Data Frame & Time Out Setting
M_DEF
AULT
Family Code Selection P.C Parameter Selection Option Code
Handshaking Protocol
SS
SS
SS
SS
None (free running mode)
RTS/CTS (hardware handshaking)
ACK/NAK (software handshaking)
Xon/Xoff (software handshaking)
0
1
2
3
Baud Rate (BPS)
SS
SS
SS
SS
38.4K BPS
19.2K BPS
9600 BPS
4800 BPS
2400 BPS
1200 BPS
600 BPS
300 BPS
0
1
2
3
4
5
6
7
Data Frame
SS
SS
SS
SS
SS
SS
SS
SS
8, None, 1
8, Odd, 1
8, Even, 1
8, Space, 1
8, Mark, 1
8, None, 2
7, Odd, 1
7, Even, 1
7, Space, 1
7, Mark, 1
7, None, 2
7, Odd, 2
7, Even, 2
7, Space, 2
7, Mark, 2
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
Time Out Control
SS
SS
SS
MS
None
200 mseconds
500 mseconds
1 second
2 seconds
5 seconds
User defined value (seconds)
0
1
2
3
4
5
6, (2 digits)

When the
RTS/CTS Hardware Handshaking
option is selected, the
RTS
(request to send) and
CTS
(clear to send) signals will be is
sued before normal
data communication. T
his option is very helpful to ensure
the reliability of data communication.

When the
AC
K/NAK Software Handshaking
option is selected, the DelfiScan waits for an
ACK
(acknowledge) or
NAK
(not acknowledge) from th
e
host com
puter after each data transmission. If the NAK is received, DelfiScan will re-send the data until receiving AC
K.

The
Tim
e Out Control
is a pre-defined delay time for DelfiScan to wait for handshaking, acknowledgment or non-acknowledgment from
the host
comput
er.
