Delfield 8159-EFP - Page 11

Part Number: 9291458 REV00 12/19 11
Section 2 Installation
Model Length Depth Height 12x20
Pans
N8100NBP Series
N8146NBP 46.75”
(119cm)
18”
(46cm)
21.81”
(55cm)
2
N8168NBP 67.5”
(171cm)
18”
(46cm)
21.81”
(55cm)
3
N8100NB-E Export Series
N8146NB-E 46.75”
(119cm)
18”
(46cm)
21.81”
(55cm)
2
N8168NB-E 67.5”
(171cm)
18”
(46cm)
21.81”
(55cm)
3
N8200P Series
N8231P 31.75"
(81cm)
26”
(66cm)
15.75”
(40cm)
NA
N8245P 45.63”
(116cm)
26”
(66cm)
15.75”
(40cm)
NA
N8259P 59.5”
(151cm)
26”
(66cm)
15.75”
(40cm)
NA
N8273P 73.38"
(186cm)
26”
(66cm)
15.75”
(40cm)
NA
N8287P 87.25”
(222cm)
26”
(66cm)
15.75”
(40cm)
NA
N8200-E Export Series
N8231-E 31.75"
(81cm)
26”
(66cm)
15.75”
(40cm)
NA
N8245-E 45.63”
(116cm)
26”
(66cm)
15.75”
(40cm)
NA
N8259-E 59.5”
(151cm)
26”
(66cm)
15.75”
(40cm)
NA
N8273-E 73.38"
(186cm)
26”
(66cm)
15.75”
(40cm)
NA
N8287-E 87.25”
(222cm)
26”
(66cm)
15.75”
(40cm)
NA
N8200GP Series
N8231GP 31.75”
(81cm)
25.87”
(66cm)
19”
(48cm)
NA
N8245GP 45.63”
(116cm)
25.87”
(66cm)
19”
(48cm)
NA
N8259GP 59.5”
(151cm)
25.87”
(66cm)
19”
(48cm)
NA
N8273GP 73.38”
(186cm)
25.87”
(66cm)
19”
(48cm)
NA
N8200G-E Export Series
N8231G-E 31.75”
(81cm)
25.87”
(66cm)
19”
(48cm)
NA
N8245G-E 45.63”
(116cm)
25.87”
(66cm)
19”
(48cm)
NA
N8259G-E 59.5”
(151cm)
25.87”
(66cm)
19”
(48cm)
NA
N8200-STP Series
N8230-STP 29.60"
(75cm)
22”
(56cm)
15.70”
(40cm)
NA
N8240-STP 39.70”
(101cm)
29.60”
(75cm)
15.70”
(40cm)
NA
N8256-STP 55.60”
(141cm)
22”
(56cm)
15.70”
(40cm)
NA
N8258-STP 57.60"
(146cm)
29.60”
(75cm)
15.70”
(40cm)
NA
N8275-STP 75.50"
(192cm)
29.60”
(75cm)
15.70”
(40cm)
NA
Model Length Depth Height 12x20
Pans
N8600P Series
N8630P 30.75”
(78cm)
26”
(66cm)
23.75”
(60cm)
2
N8643P 43.5”
(110cm)
26”
(66cm)
23.75”
(60cm)
3
N8656P 56.25”
(143cm)
26”
(66cm)
23.75”
(60cm)
4
N8669P 69”
(175cm)
26”
(66cm)
23.75”
(60cm)
5
N8681P 81.75”
(208cm)
26”
(66cm)
23.75”
(60cm)
6
N8700D Series
N8717-D 17.88”
(45cm)
26”
(66cm)
9.5”
(24cm)*
1
N8731-D 31.75”
(81cm)
26”
(66cm)
9.5”
(24cm)*
2
N8745-D 45.63”
(116cm)
26”
(66cm)
9.5”
(24cm)*
3
N8759-D 59.5”
(151cm)
26”
(66cm)
9.5”
(24cm)*
4
N8773-D 73.38”
(186cm)
26”
(66cm)
9.5”
(24cm)*
5
N8787-D 87.25”
(222cm)
26”
(66cm)
9.5”
(24cm)*
6
*14” Overall height including drain connection
N8700D-E Export Series
N8717-D-E 17.88”
(45cm)
26”
(66cm)
9.5”
(24cm)*
1
N8731-D-E 31.75”
(81cm)
26”
(66cm)
9.5”
(24cm)*
2
N8745-D-E 45.63”
(116cm)
26”
(66cm)
9.5”
(24cm)*
3
N8759-D-E 59.5”
(151cm)
26”
(66cm)
9.5”
(24cm)*
4
N8773-D-E 73.38”
(186cm)
26”
(66cm)
9.5”
(24cm)*
5
N8787-D-E 87.25”
(222cm)
26”
(66cm)
9.5”
(24cm)*
6
*14” Overall height including drain connection
N8700DESP Series
N8717-DESP 17.89”
(45cm)
26”
(66cm)
9.5”
(24cm)*
1
N8731-DESP 31.76”
(81cm)
26”
(66cm)
9.5”
(24cm)*
2
N8745-DESP 45.63”
(116cm)
26”
(66cm)
9.5”
(24cm)*
3
N8759-DESP 59.50”
(151cm)
26”
(66cm)
9.5”
(24cm)*
4
N8773-DESP 73.37”
(186cm)
26”
(66cm)
9.5”
(24cm)*
5
N8787-DESP 87.24”
(222cm)
26”
(66cm)
9.5”
(24cm)*
6
*14” Overall height including drain connection
