Dell EMC Data Domain DD6300 - DD6300 with ES30 Cabling Instructions

Table 3 DD6300 with ES30 cabling instructions
String
(Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0
B controller HOST port of shelf V1.1
2M
1 I/O 7 - Port 2
A controller HOST port of the highest number
shelf in V1
2M
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Connect Cables and Power On
DD6300 with ES30 cabling 25
