47
500 414916022350R RES SMD (0603) 22KΩ J,RT,RoHS 2 TA-I,WALSIN,YAGEO, R427,R431,
510 414916039350R RES SMD (0603) 39KΩ J,RT,RoHS 2 TA-I,WALSIN,YAGEO, R429,R428,
520 414916082450R RES SMD (0603) 820KΩ J,RT,RoHS 2 TA-I,WALSIN,YAGEO, R434,R435,
530 419314744060R C SMD(0603) X7R 0.47uF/16V K,RoHS 2 DARFON,TDK,WALSIN,YAGEO, C908,C927,
540 414916033250R RES SMD (0603) 3.3KΩ J,RT,RoHS 1 TA-I,WALSIN,YAGEO, R405,
550 412000358310R IC PM25LV010-25SCE SOIC8(PMC) RoHS PMC,
550 412000373190R IC SST25VF010A-33-4C-SAE,SOIC- 8(SST)RoH
1
SST,
U402,
560 506140005700R LABEL,BARCODE,BLANK,33x7mm, ROHS,FOR PCB 1 KAIDA,
570 414916010050R RES SMD (0603) 10Ω J,RT RoHS 8 TA-I,WALSIN,YAGEO,
R303,R317,R318,R321,R327,R330,R331,R335,
580 414916022350R RES SMD (0603) 22KΩ J,RT,RoHS 1 TA-I,WALSIN,YAGEO, R503,
590 419311023060R C SMD(0603) X7R 1000PF/25V K RoHS 1 DARFON,TDK,WALSIN,YAGEO, C316,
600 414908056150R RES SMD (0805) 560Ω J,RT,RoHS 1 TA-I,WALSIN,YAGEO, R504,
610 425000010720R CHOKE COM.MODE SMD 90Ω ,RoHS 2 CHILISIN,FRONTIER,TAI-TECH, L904,L906,
790581400710R PCBA,PWR&INV./B, LP1903-7G2
10 430637020020R WFR. 2P P=3.5mm 90°4100-D02 RoHS 4 ENTERY,FCN,FOXCONN, CN1,CN2,CN3,CN4,
20 440149000080R SKT AC 10A/250V U/C/V,W/NUT RoHS 1 DLK,TECX, CN850,
30 430631100040R WFR. 10P 2.0mm 180° HF5510ERoHS 1 FOXCONN,JOWLE, CN853,
40 442299001100R CON,POWER JACK R/A 1P,JPD1030- H224-4F,R 1 DLK,FOXCONN,S.C., CN855,
50 420424710312R CAP SD 470uF/35V M 105℃ F 10x20 RoHS 2 CAPXON,SU'SCON,TEAPO, C1,C9,
60 418112058520R CAP CD SL 12pF 3KV J,S7.5,RoHS 2 JETCON,JNC,TDK, C13,C18,
60 418112067520R CAP CD N750 12pF 3KV J,S7.5,RoHS VISHAY,
60 418112051520R CAP CD NPO 12pF 3KV J,S7.5, RoHS SUCCESS(SEC),
70 418103058920R CAP CD SL 3pF 3KV D,S7.5,RoHS 2 JETCON,JNC, C14,C17,
70 418103051920R CAP CD NPO 3pF 3KV D,S7.5, RoHS SUCCESS(SEC),
70 418103051820R CAP CD NPO 3pF 3KV C,S7.5,RoHS VISHAY,
80 420424710430R CAP SD 470uF/16V M 105℃ VT 10x13 RoHS 2 CAPXON,SU'SCON,TEAPO, C807,C809,
90 416202223610R CAP MEY 2200pF 250V M Y2 Y5V P=7.5mm RoH 2 JNC,POE,SUCCESS(SEC),TDK, C850,C851,
100 416193343012R CAP MEX 0.33uF 275V K X2,F15mm RoHS 1 ARCOTRONIC,HJC,TEAPO, C852,
110 416191043010R CAP MEX 0.1uF 275V K X2,F15 RoHS 1 ARCOTRONIC,HJC,PANASONIC,TEAPO, C853,
120 420431014583R CAP SEK 100uF/450V M,105℃ CF,16x45,RoHS 1 CAPXON,SU'SCON, C854,
130 416213323620R CAP MEY 3300pF 250V M Y1,F10mm W/O FORMI 1 POE,SUCCESS(SEC), C860,
130 416203324620R CAP MEY 3300pF 400V M Y,P10mm W/O FORMIN JNC,
140 420424710311R CAP SD 470uF/35V M 105℃ F, 13x16,RoHS 4 CAPXON,SU'SCON, C862,C864,C865,C806,
150 420426810210R CAP SD 680uF/25V M 105℃ F 10x20 RoHS 1 CAPXON,SU'SCON,TEAPO, C871,
160 416304723510R CAP PP 0.0047uF 250V J,F7.5 RoHS 1 DAE HUNG,HJC, C880,
170 411050007010R DIO BRDG KBL405G 600V/4A(TSC) RoHS 1 TSC, D850,
