Service Manual
170 411050005090R DIO BRDG FL406 600V/4A(PEC)RoH S PANJIT,
180 411090034090R SCHTKY SB340-F 40V/3A DO-201AD(PANJIT)Ro 1 PANJIT, D857,
180 411090034021R SCHTKY SR304F54-LF 40V/3A DO201AD(FEC)Ro FRONTIER,
190 412140002380R IC LTV817M-PR VDE (LITE-ON) P=10mm RoHS 1 LITEON, I850,
190 412140001390R IC EL817M-B(EVERLIGHT)RoHS EVERLIGHT,
200 425000010710R COIL CHK 2.8uH T60-18 CHK-071,RoHS 1 CHILISIN,FRONTIER, L801,
210 425000010700R COIL CHK 16.8mH UU16 CHK-070, RoHS 1 CHILISIN,DARFON,FRONTIER,TDK, L851,
220 425000010690R COIL CHK 4.5uH DR10x10 CHK-069 RoHS 1 CHILISIN,EASYMAGNET,FRONTIER, L853,
230 425000010570R COIL CHK 50uH/3A TORO CHK-057 RoHS 1 CHILISIN,FRONTIER, L855,
240 425000010530R COIL CHK 5uH 7.8X10 CHK-053 0 181085R0L 1 CHILISIN,FRONTIER,TDK, L856,
250 414040208540R RES FSM 1W 0.2Ω J,AT MINI RoHS 1 QUEENMAO,TZAI YUAN, R852,
260 415350338520R RES MOF 2W 0.33Ω J VF,MINI, RoHS 1 QUEENMAO,TZAI YUAN, R859,
270 415350100520R RES MOF 2W 10Ω J,MINI,VF,RoHS 1 QUEENMAO,TZAI YUAN, R860,
280 415350823520R RES MOF 2W 82KΩ J,VF MINI, RoHS 1 QUEENMAO,TZAI YUAN, R880,
290 432009401000R NTC 8Ω 5A +-20% 15ψ P=7.5mm,RoHS 1 THINKING,UPPERMOST, RT850,
300 426000090600R XFMR SW,DIP EEL19 SPW-060,RoHS 2 DARFON,FRONTIER,LISHIN,TDK,XTREME,
T2,T1,
310 426000090590R XFMR SW,450uH,ERL28 SPW-059,DIP RoHS 1 DARFON,FRONTIER,LISHIN,TDK, T850,
320 432009500050R VARIST. 560V,F7.5(THINKING) RoHS 1 BRIGHTKING,THINKING, VZ850,
350 790582100000R PCBA,CONTROL/B,(INV.), LP1X03 1
360 790582101000R PCBA,CONTROL/B(PWR A-D),LP1X03 1
370 790582102000R PCBA,CONTROL/B(PWR D-D),LP1X03 1
380 790581410710R PCBA,PWR&INV./B,AI,LP1903-7G2 1
390 790581430A00R PCBA,PWR&INV/B,PRE-F, LP1703-AG2 1
400 502040604300R SHIELD,EMI, LE1512 1 ORIENTAL POWER,TOP RICH, SP1,
410 432002200190R FERR BEAD 3.5x9x0.65,VT,RoHS,RH03509ST-B 2 CHILISIN,TAI-TECH, L802,L803,
420 420422210330R CAP SD 220uF/35V M 105℃ VT,10x13,RoHS 1 CAPXON,SU'SCON,TEAPO, C869,
430 420422210260R CAP SD 220uF 25V M,105℃ ST 8x12 RoHS 1 CAPXON,SU'SCON,TEAPO, C813,
790581410710R PCBA,PWR&INV./B,AI,LP1903-7G2
10 790581450710R PCBA,PWR&INV./B,AI/A, LP1903-7G2 1
20 790581460A10R PCBA,PWR&INV./B,AI/R, LP1903-AG2 1
790581430A00R PCBA,PWR&INV/B,PRE-F, LP1703-AG2
10 735100007000R ASSY,H/S,D854, LP1X03 ROHS 1
20 735100007010R ASSY,H/S,Q801, LP1X03 ROHS 1
30 735100007020R ASSY,H/S,Q850, LP1X03 ROHS 1
40 735100007030R ASSY,H/S,U851, LP1X03 ROHS 1
790582100000R PCBA,CONTROL/B,(INV.), LP1X03
