Dell 2407WFP - Monitor Specifications; General & Flat Panel Specs; Resolution & Video Modes

Monitor Specifications
1 AC power cord connector
2 DC power connector for Dell Soundbar
3 DVI connector
4 VGA connector
5 Composite video connector
6 S-Video connector
7 Component video connectors
8 USB upstream port
9 USB downstream ports
General
Model number 2407WFP
Flat Panel
Screen type Active matrix - TFT LCD
Screen dimensions 24 inches (24-inch viewable image size)
Preset display area:
Horizontal 518.4 mm (20.4 inches)
Vertical 324.0 mm (12.7 inches)
Pixel pitch 0.270 mm
Viewing angle +/- 89 (vertical) typ, +/- 89 (horizontal) typ
Luminance output 450 cd/m (typ)
Contrast ratio 1000:1 (typ)
Faceplate coating Antiglare with hard-coating 3H
Backlight 6 CCFLs U-type backlight
Response Time 6 ms typical (Grey to Grey) / 16 ms typical (Black to White)
Resolution
Horizontal scan range 30 kHz to 81 kHz (automatic)
Vertical scan range 56 Hz to 76 Hz, exception 1920 x 1200 at 60 Hz only
Optimal preset resolution 1920 x 1200 at 60 Hz
Highest preset resolution 1920 x 1200 at 60 Hz
Video Supported Modes
Video display capabilities (DVI playback) 480p/576p/720p/1080p (Supports HDCP)
Video display capabilities (Composite playback) NTSC/PAL
Video display capabilities (S-Video playback) NTSC/PAL
Video display capabilities (Component playback) 480i/480p/576i/576p/720p/1080i
Preset Display Modes
Dell™ guarantees image size and centering for all preset modes listed in the following table.
