4. Place and align the front I/O-bracket with I/O slot on the chassis.
5. Replace the screw (#6-32) that secures the front I/O-bracket to the chassis.
Next steps
1. Install the processor.
2. Install the heat-sink and fan assembly.
3. Install the WLAN card.
4. Install the solid-state drive.
5. Install the memory modules.
6. Install the expansion card.
7. Install the Optional I/O modules.
8. Install the disk-drive cage.
9. Install the 3.5-inch hard drive if applicable.
10. Install the 2.5-inch hard drive if applicable.
11. Install the front bezel.
12. Install the side cover.
13. Follow the procedure in After working inside your computer.
Rimozione e installazione di unità sostituibili sul campo (FRU) 101
