Dell 9478N - Connettore Dellalimentatore; GPU - Integrata; External Display Support (GPU-Integrated)

Tabella 14. Potenza nominale (continua)
Descrizione Opzione uno Opzione due
In funzione
5°C to 45°C (41°F to 113°F) 5°C to 45°C (41°F to 113°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
Connettore dell'alimentatore
La tabella seguente elenca le specifiche del connettore dell'alimentatore di OptiPlex Small Form Factor 7010.
Tabella 15. Power supply connector
180 W (80 Plus Bronze)
● Two 4 pin connectors for processor
● One 8 pin connector for system board
300 W (80 Plus Platinum)
● Two 4 pin connectors for processor
● One 8 pin connector for system board
GPU - Integrata
La seguente tabella elenca le specifiche della GPU integrata supportata da OptiPlex Small Form Factor 7010.
Tabella 16. GPU - Integrata
Controller Supporto display esterno Dimensione memoria Processore
Intel UHD Graphics 710 Three DisplayPort 1.4a /
One HDMI 1.4b port
(1920x1200@60Hz max.
resolution)
Shared system memory Intel Celeron G6900 and
Intel Pentium Gold G7400
processors
Intel UHD Graphics 730 Three DisplayPort 1.4a /
One HDMI 1.4b port
(1920x1200@60Hz max.
resolution)
Shared system memory 13th Generation Intel Core
i3-13100 and i5-13400
processors
Intel UHD Graphics 770 Three DisplayPort 1.4a /
One HDMI 1.4b port
(1920x1200@60Hz max.
resolution)
Shared system memory 13th Generation Intel
Core i5-13500,i5-13600,
processors
External display support (GPU—Integrated)
Display support for the integrated graphics card
Table 17. Display support specifications
Graphics card Supported external displays
Intel UHD Graphics 710/730/770 4
Intel UHD Graphics 710/730/770 + optional module 4
Specifiche di OptiPlex Small Form Factor 7010 25
