Dell Alienware Aurora R15 User Manual

Wireless card
Removing the wireless card
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
About this task
The following images indicate the location of the wireless card and provide a visual representation of the removal procedure.
Steps
1. Remove the screw (M2x3) that secures the wireless card to the system board.
2. Lift the wireless-card bracket off the wireless card.
3. Disconnect the antenna cables from the wireless card.
4. Slide and remove the wireless card from the wireless-card slot.
Installing the wireless card
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
CAUTION: To avoid damage to the wireless mini-card, do not place any cables under it.
Removing and installing components 71

Dell Alienware Aurora R15 Specifications

General

Chipset	Intel Z790
Processor Options	13th Gen Intel Core i9-13900KF
Graphics Options	NVIDIA GeForce RTX 4090
Memory	Up to 64GB DDR5
Storage Options	Up to 4TB NVMe SSD + Up to 2TB 7200RPM SATA HDD
Power Supply	1350W Platinum-rated PSU
Cooling	Liquid-cooled CPU and high-performance air cooling options
Operating System	Windows 11 Home, Windows 11 Pro
Front Ports	1x USB 3.2 Gen 2 Type-C
Wireless	Wi-Fi 6E (802.11ax), Bluetooth 5.2
Dimensions	510mm
Weight	16 kg
