48
CHAPTER 5: INSTALLING ADDITIONAL OR REPLACEMENT COMPONENTS
Remove the interposer from the hard drive.7.
1
2
1 interposer 2 hard drive
To replace the hard drive, perform the removal steps in reverse order.
Remove the four screws that secure the hard drive to the hard drive bracket.5.
Lift the hard drive out of the hard drive bracket.6.
3
1
2
1 hard drive 3 screws (4)
2 hard drive bracket
