Dell Alienware M15x - Hard Drive Upgrade and Replacement

47
CHAPTER 5: INSTALLING ADDITIONAL OR REPLACEMENT COMPONENTS
Upgrading or Replacing the Hard Drive
Your laptop is equipped with one hard drive socket.
Removing the Hard Drive
Follow the instructions in “Before You Begin” on page 1. 42.
Loosen the two screws and remove the compartment door.2.
2
1
1 screws (2) 2 compartment door
Loosen the four captive screws on the hard drive.3.
Lift the hard drive out.4.
1
2
1 hard drive 2 captive screws (4)
