Table 24. Screw list(continued)
Component Secured to Screw type Quantity Screw image
System board Palm-rest and keyboard
assembly
M2x4 7
Fan and heat-sink
assembly
System board M2x3 6
I/O-board Palm-rest and keyboard
assembly
M2x2.5 4
Power button Palm-rest and keyboard
assembly
M1.2x2 2
Major components of Alienware x16 R2
The following image shows the major components of Alienware x16 R2.
