6. Slide the touchpad-light cable into the connector on the keyboard-controller board and close the latch to secure the cable.
NOTE: Your computer may be shipped with a touchpad-light cable depending on the configuration you have ordered.
7. Slide the keyboard-backlight cable into the connector on the keyboard-controller board and close the latch to secure the cable.
8. Place the Mylar that secures the keyboard-controller board to the palm-rest and keyboard assembly.
NOTE: For models shipped with a per-key or mechanical keyboard, the computer will require a keyboard language and
keyboard color setup after keyboard-controller board is replaced. When the computer is reassembled and turned on, an
error message is displayed. Press F2 to go to the Keyboard section of the BIOS Setup Utility to set up the keyboard language
and keyboard color. See the bundled Tech Sheet for details on configuring the keyboard language.
Next steps
1. Install the battery.
2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Display assembly
Removing the display assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the
base cover.
3. Remove the rear I/O-cover.
About this task
NOTE: The display assembly is a Hinge-Up Display (HUD) and cannot be further disassembled.
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
68
