NOTE: Your computer may be shipped with a touchpad-light cable depending on the configuration you have ordered.
10.Peel the tape that secures the touchpad to the palm-rest and keyboard assembly.
11. Remove the nine screws (M1.6x1.8) that secure the touchpad to the palm-rest and keyboard assembly.
12. Lift the touchpad off the palm-rest and keyboard assembly.
Installing the touchpad
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following images indicate the location of the touchpad and provide a visual representation of the installation procedure.
58
