Dell B2360DN Mono Laser User Manual

3 Align the notch (1) on the memory card with the ridge (2) on the connector.
1
2
4 Push the memory card straight into the connector, and then push the card toward the controller board wall until
it clicks into place.
1
2
5 Close the controller board access door.
Note: When the printer software and any hardware options are installed, it may be necessary to manually add the
options in the printer driver to make them available for print jobs. For more information, see “Updating available
options in the printer driver” on page 22.
Additional printer setup 16

Dell B2360DN Mono Laser Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Connectivity	USB 2.0, Ethernet
Duplex Printing	Yes
Output Capacity	150 sheets
Print Speed	Up to 40 ppm
Monthly Duty Cycle	80000 pages
Input Capacity	250 sheets
Memory	128 MB
First Page Out	6.5 sec
Operating Systems Supported	Linux
