Dell B2360DN Mono Laser User Manual

8 Insert the toner cartridge by aligning the side rails of the cartridge with the arrows on the side rails inside the printer,
and then insert the cartridge into the printer.
9 Close the front door.
10 From the printer control panel, press to clear the message and continue printing.
Jam, rear door [20y.xx]
1 Press the button on the right side of the printer, and then open the front door.
2 Gently pull down the rear door.
CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching it.
Clearing jams 107

Dell B2360DN Mono Laser Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Connectivity	USB 2.0, Ethernet
Duplex Printing	Yes
Output Capacity	150 sheets
Print Speed	Up to 40 ppm
Monthly Duty Cycle	80000 pages
Input Capacity	250 sheets
Memory	128 MB
First Page Out	6.5 sec
Operating Systems Supported	Linux
