Page #21 background imageLoading...
Page #21 background image
1
2
3
4
5
6
7
Use the To
1
USB port
*
Attach an optional wireless network adapter.
2 USB printer port Connect the printer to a computer.
3
Ethernet port
*
Connect the printer to a network.
4
Parallel port
*
Connect the printer to a computer.
5 Power switch Turn on or turn off the printer.
6 Printer power cord socket Connect the printer to an electrical outlet.
7 Security slot Attach a lock that will secure the printer in place.
*
These ports are available only in select printer models.
Setting up the printer software
Installing the printer software
Note: If you installed the printer software on the computer before but need to reinstall the software, then uninstall
the current software first.
For Windows users
1
Close all open software programs.
2 Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then launch the CD manually:
a Click , or click Start and then click Run.
b In the Start Search or Run dialog, type D:\setup.exe, where D is the letter of your CD or DVD drive.
Additional printer setup 21

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell B2360DN Mono Laser and is the answer not in the manual?

Dell B2360DN Mono Laser Specifications

General IconGeneral
Print TechnologyLaser
Print Resolution1200 x 1200 dpi
Standard ConnectivityUSB 2.0, Ethernet
Duplex PrintingYes
Output Capacity150 sheets
Print SpeedUp to 40 ppm
Monthly Duty Cycle80000 pages
Input Capacity250 sheets
Memory128 MB
First Page Out6.5 sec
Operating Systems SupportedLinux
