Dell D825TM - Power Saving Function; Timing Specification

— 2 —
D825TM
State Power Required u Power indicator
consumption recovery time
POWER SAVING FUNCTION
This monitor has three Power Saving modes.
By sensing the absence of a video signal from the
computer, it reduces power consumption as follows:
NOTE:
TIMING SPECIFICATION
MODE 1 2 3 4 5 6 7 8 9 10
Resolution (H x V) 640X480 720X400 640X480 640X480 800X600 800X600 800X600 1024X768 1024X768 1280X1024
Dot Clock (MHz) 25.175 28.321 31.500 36.000 40.000 49.500 56.250 78.750 94.500 108.000
HORIZONTAL
Hor. Freq. (kHz) 31.469 31.468 37.500 43.269 37.879 46.875 53.674 60.023 68.677 63.981
H-Total 31.778 31.779 26.667 23.111 26.400 21.333 18.631 16.660 14.561 15.630
H-Blanking 6.356 6.356 6.349 5.333 6.400 5.172 4.409 3.657 3.725 3.778
H-Front Porch 0.636 0.636 0.508 1.556 1.000 0.323 0.569 0.203 0.508 0.444
H-Sync. 3.813 3.178 2.032 1.556 3.200 1.616 1.138 1.219 1.016 1.037
H-Back Porch 1.907 2.542 3.810 2.222 2.200 3.232 2.702 2.235 2.201 2.296
H-Active 25.422 25.423 20.317 17.778 20.000 16.162 14.222 13.003 10.836 11.852
(µsec)
VERTICAL
Ver. Freq. (Hz) 59.940 70.084 75.000 85.008 60.317 75.000 85.061 75.029 84.997 60.020
V-Total 525 449 500 509 628 625 631 800 808 1066
V-Blanking 45 49 20 29 28 25 31 32 40 42
V-Front Porch 10 13 1 1 1 1 1 1 1 1
V-Sync. 2 2 3 3 4 3 3 3 3 3
V-Back Porch 33 34 16 25 23 21 27 28 36 38
V-Active 480 400 480 480 600 600 600 768 768 1024
(lines)
SYNC.
Int(G) NO NO NO NO NO NO NO NO NO NO
Ext (H/V)/Polarity YES -/- YES -/+ YES -/- YES -/- YES +/+ YES +/+ YES +/+ YES +/+ YES +/+ YES +/+
Ext (CS)/Polarity NO NO NO NO NO NO NO NO NO NO
Int / Non Int Non Int Non Int Non Int Non Int Non Int Non Int Non Int Non Int Non Int Non Int
1. Normal Operation < 110W Green on
2. Standby (1st mode)
< 15W approx. 3 sec. Green and orange
alternate
3. Suspend (2nd mode)
<15W Approx. 3 sec. Green and orange
alternate
4. Active-off (3rd mode)
<8W Approx. 10 sec. Orange
5. Power-off 0W Off
6. Failure mode Orange flashing
If no video signal is input to the monitor, the
"NO INPUT SIGNAL" message appears. After
about 30 seconds, the Power Saving function
automatically puts the monitor into active-off
mode and the indicator lights up orange. Once
the monitor detects horizontal and vertical sync
signals, the monitor automatically resumes
normal operation mode.
